Workflows Made Easy

The Astro Python SDK is a Python SDK designed for the rapid development of extract, transform, and load workflows in Apache Airflow. This SDK allows you to express your workflows as a set of data dependencies, freeing you from the burden of managing orderings and tasks. It is maintained by Astronomer.

Prerequisites

• Apache Airflow = 2.1.0

Installation

To get started with the Astro Python SDK, follow these installation steps:

• The Astro Python SDK is available at PyPI. Utilize the standard Python installation tools to install it.
• For a cloud-agnostic version of the SDK, run:

pip install astro-sdk-python

• To install dependencies for specific cloud providers, run:

pip install astro-sdk-python[amazon,google,snowflake,postgres]

Quickstart

Follow these steps to quickly get your Airflow environment set up:

1. Ensure your Airflow environment is correctly set up:

export AIRFLOW_HOME=$(pwd)
airflow db init

Note:

• As of astro-sdk-python release 1.2 and above, AIRFLOW__CORE__ENABLE_XCOM_PICKLING does not need to be enabled.
• For Airflow version 2.5 and astro-sdk-python release 1.3, refer to AstroCustomXcomBackend.
2. Create a SQLite database:

export SQL_TABLE_NAME=$(airflow connections get sqlite_default -o yaml | grep host | awk '{print $2}')
sqlite3 $SQL_TABLE_NAME VACUUM;

3. Copy the following workflow into a file named calculate_popular_movies.py and add it to the dags directory:

calculate_popular_movies.py

4. Run the example DAG:

airflow dags test calculate_popular_movies date -I seconds

5. Check the results by running:

sqlite3 $SQL_TABLE_NAME "select * from top_animation;" .exit

You should see entries like:

Toy Story 3 (2010) 8.3
Inside Out (2015) 8.2
How to Train Your Dragon (2010) 8.1
Zootopia (2016) 8.1
How to Train Your Dragon 2 (2014) 7.9

Supported Technologies

The Astro Python SDK supports various file locations and types:

File Location:

• local
• http
• https
• gs (Google Storage)
• gdrive
• s3
• wasb
• wasbs
• azure
• sftp
• ftp

File Type:

• csv
• json
• ndjson
• parquet
• xls
• xlsx

Database:

• postgres
• sqlite
• delta
• bigquery
• snowflake
• redshift
• mssql
• duckdb
• mysql

Available Operations

The following are some key functions available in the SDK:

• load_file: Load a file into a SQL table.
• transform: Apply a SQL select statement to a source table and save the result to a destination table.
• drop_table: Drop a SQL table.
• run_raw_sql: Run SQL statements without handling output.
• append: Insert rows from the source SQL table into the destination SQL table.
• merge: Insert rows from the source SQL and manage conflicts.
• export_file: Export SQL table rows into a file.
• dataframe: Export a SQL table into an in-memory Pandas dataframe.

For a complete operators list, visit the SDK reference documentation.

Troubleshooting

If you encounter issues while using the Astro Python SDK, try these troubleshooting steps:

• Ensure your Airflow version is compatible (2.1.0 or higher).
• Check that your Python installation is up-to-date.
• Verify that your dependencies were installed correctly.
• If the DAG does not run as expected, ensure the correct workflow file is in the proper location within the dags directory.
