Bastillion for EC2 is a powerful web-based SSH console designed to facilitate the management of multiple EC2 instances on Amazon Web Services (AWS). It allows users to execute commands, share terminal commands, and upload files across different instances simultaneously. This blog post will guide you through various aspects of using Bastillion for EC2, from installation to management, while troubleshooting common issues.

Understanding the Basics of Bastillion for EC2

Imagine you are a conductor of an orchestra, and each musician (your EC2 instances) can play their notes (commands) simultaneously or selectively. Bastillion acts as the baton that allows you to direct your musicians efficiently toward a harmonious performance (effective server management). Just as a conductor can choose which instruments to highlight, you can select specific instances to run commands or scripts. This powerful functionality allows you to manage a symphony of servers effortlessly.

Prerequisites

• Open-JDK or Oracle JDK 1.9 or greater
• Install Authy or Google Authenticator for two-factor authentication

How to Run Bastillion-EC2 Bundled with Jetty

1. Download the Bastillion-EC2 package from GitHub Releases.
2. Set the necessary environment variables for your operating system.

   For Linux/Unix/OSX:

   export JAVA_HOME=path-to-jdk
   export PATH=$JAVA_HOME/bin:$PATH

   For Windows:

   set JAVA_HOME=C:\path-to-jdk
   set PATH=%JAVA_HOME%\bin;%PATH%

3. Start Bastillion:
   • For Linux/Unix/OSX: . startBastillion-EC2.sh
   • For Windows: startBastillion-EC2.bat

Using Bastillion-EC2

1. Open your browser and navigate to https://:8443.
2. Login with:
   • Username: admin
   • Password: changeme (For AMI instances, default is the Instance ID)
3. Configure an IAM Role with your Account ID and set the ARN in Bastillion-EC2.
4. Import the Bastillion-EC2 public SSH key in the EC2 AWS console.
5. Create EC2 instances using the imported key.
6. Start composite-SSH sessions or create scripts for multiple sessions.
7. Add instance administrators and monitor their sessions.

Managing User Access and SSH Key Pairs

User access can be restricted via tags in a user’s profile, ensuring that only authorized users can manage specific instances. You can also supply a custom SSH key pair by editing the Bastillion-EC2 Config.properties file.

Example Configuration for Custom SSH Key

# regenerate SSH keys
resetApplicationSSHKey=true
sshKeyType=rsa
privateKey=/Users/kavanagh/.ssh/id_rsa
publicKey=/Users/kavanagh/.ssh/id_rsa.pub
defaultSSHPassphrase=myPa$$w0rd

Troubleshooting Common Issues

• If you encounter issues logging in, make sure your firewall settings allow traffic on port 8443 or 443.
• If the application doesn’t start, ensure you have the correct Java version and environment variables set.
• For issues with SSH keys, double-check your key file paths in the Bastillion-EC2 Config.properties.
• If terminal sessions are slow, verify your network connection and instance performance.
