Welcome to the fascinating world of fall detection using pose estimation! Here, we’ll explore how to harness the power of the OpenPifPaf library to create a reliable fall detection system that can operate seamlessly on both complex scenarios and single-user environments.

Introduction

The fall detection model based on OpenPifPaf delivers a robust solution capable of detecting falls in crowded scenes with multiple persons. Unlike traditional models, this innovative approach incorporates a person tracker, enhancing accuracy. Whether you’re using a GPU or CPU, this model ensures you won’t miss a beat, regardless of whether you’re working with videos, RTSP streams, or USB webcams.

Demo Videos

Before jumping into the technical details, let’s take a look at some demo videos that showcase this model in action:

• Walking Trip
• Stubbed Toe
• Drunk

Video credits: 50 Ways to Fall (Link), ran on a single NVIDIA Quadro P1000.

Test Results

Using the UR Fall Detection Dataset (Link), the model was tested on two NVIDIA Quadro GV100s and showed impressive performance:

• Precision: 100%
• Recall: 83.33%
• F1 Score: 90.91%

Note: Due to the lack of available datasets, false positives and true negatives were not tested.

Environment Setup

To get started, you’ll need the following environment:

• Ubuntu 18.04 x86_64
• Python 3.7.6
• Anaconda 3
• CUDA 10.2

How to Set Up the Fall Detection System

Follow these steps to set up your fall detection system:

1. Setup Conda Environment

conda create --name falldetection_openpifpaf python=3.7.6
conda activate falldetection_openpifpaf

2. Clone the Repository

git clone https://github.com/cwlrodafalldetection_openpifpaf.git

3. Download OpenPifPaf 0.11.9 (PyPI)

pip3 install openpifpaf

4. Copy Source Files

Navigate to the following directory:

cd home_dir/anaconda3/lib/python3.7/site-packages/openpifpaf

Now, replace ALL files in that folder with the files in the falldetection_openpifpaf directory.

5. Install Dependencies

pip3 install -r requirements.txt

6. Execution

For videos and RTSP streams, you need to edit the video/RTSP stream path in the _config/config.xml file. Then run:

python3 -m openpifpaf.video --show

(Use --help to see the full list of command line arguments.)

For webcams or USB cameras, run:

python3 -m openpifpaf.video --source CAMERA_ID --show

(Again, use --help for more options.)

Troubleshooting

While setting up and running your fall detection model, you might encounter some common issues, such as:

• Camera not detected: Ensure your webcam is properly connected and recognized by your operating system.
• Errors during the installation of dependencies: Double-check your Python version and ensure that your Anaconda setup is correct.
• Performance lags: If you’re running on an older system, consider closing unnecessary applications to free up resources.
