Welcome to this guide on the PyTorch implementation of “Geometry-Aware Learning of Maps for Camera Localization.” This incredible technology, introduced at CVPR 2018, offers innovative solutions for navigating environments using camera images.

Table of Contents

• Documentation
• Setup
• Data
• Running the Code
  • Demo Inference
  • Train
  • Network Attention Visualization
  • Other Tools
• FAQ
• License

Setup

To get started with MapNet, we will need to set up a Conda environment to manage our dependencies efficiently.

1. Install miniconda with Python 2.7.
2. Create the MapNet Conda environment:

conda env create -f environment.yml

3. Activate the environment:

conda activate mapnet_release

4. Ensure that your code is compatible with PyTorch v0.4.1, which should be installed via the environment.yml file.

Data

The implementation supports two datasets, 7Scenes and Oxford RobotCar. Here’s how to get your data ready:

1. Create symlinks to your dataset directories:

cd datadeepslam_data
ln -s 7SCENES_DIR 7Scenes
ln -s ROBOTCAR_DIR RobotCar_download

2. For specific RobotCar setup, download the dataset SDK and run the symlink script.

Running the Code

This implementation allows you to test models and run training. Now let’s analyze the commands we’ll be executing using an analogy: Think of training different recipes for various dishes. Each recipe represents a different model you can cook up!

• Demo Inference: You’re testing a recipe (model) to see if it tastes good (performs well). Using different command flags, you can adjust spices (hyperparameters) and cooking times (data configurations).
• Training: Just like practicing a dish to perfect it, you’ll use training commands to refine your model. You’ll adjust the ingredients (data) and the cooking method (training script).
• Visualizations: Once you’ve created your dish, you’d want to showcase it beautifully—this is where network attention visualizations come into play!

Demo Inference

To see the models in action, use the following command for working with the 7Scenes dataset:

python eval.py --dataset 7Scenes --scene heads --model mapnet++ --weights logs/7Scenes_heads_mapnet++_mapnet++_7Scenes_epoch_005.pth.tar --val

This command checks model performance, and make sure to check out other models for different datasets or scenes!

Train

To train your model from scratch or fine-tune it like adjusting your recipe, execute:

python train.py --dataset 7Scenes --scene chess --config_file configs/mapnet++.ini --model mapnet++ --device 0 --learn_beta --learn_gamma

Here you can customize and enhance your training recipe further.

Network Attention Visualization

Curious about how your model pays attention to different parts of the input data? You can visualize that with:

python plot_activations.py --dataset 7Scenes --scene chess --weights filename.pth.tar --device 1 --val --config_file configs/mapnet.ini --output_dir ../results

Other Tools

These handy scripts make your life easier!

• Align VO to the ground truth poses
• Calculate pixel statistics
• Plot ground truth and VO poses for better debugging

FAQ

If you experience some hiccups along the way or have questions about reproducing results, data, or hyperparameters, check out the community discussions on our GitHub issues page.

License

This project is licensed under the CC BY-NC-SA 4.0 license. Enjoy cooking up your models responsibly!

Troubleshooting

While embarking on your project, you might encounter a few challenges such as missing datasets or installation errors. Here are some troubleshooting tips:

• Ensure Conda and all dependencies are set up correctly.
• Double-check dataset paths and create symlinks as needed.
• If you see version errors, you may need to manually install the specified PyTorch version.
