How to Create a Customizable Step Component with Svelte

Nov 6, 2023 | Programming

homemayankDocumentsarticle-generation-using-llmresized_images_gitbootstrapreadme_shaozi_svelte-steps

Welcome to this guide on creating a customizable step component using Svelte! This powerful tool can be tailored to fit your application’s needs, allowing for a sleek user experience with numerous customization options. Let’s dive into the process of setting up your own step component from scratch.

Installation

Before we jump into the configuration details, you need to install the necessary package. To do this, run the following command in your terminal:

npm install --save-dev svelte-steps

Example Usage

After installation, you can begin utilizing the svelte-steps component. Clone this project and run it to see an example in action! You can also check out the homepage here for more insights. The source file for the demo is located at src/routes/index.svelte.

Basic Usage

Here’s how to get started with a basic step component:

script
    import Steps from 'svelte-steps';
    let steps = [
        { text: "step one" },
        { text: "step two" },
        { text: "the last step" }
    ];
/script

Steps {steps}

Using Vertical Steps

If you want your steps to be vertical, simply add the vertical prop as shown below. Note that this requires Svelte version 3.46.3 or newer.

Steps vertical {steps}

You can also reverse the order to place the text label to the left:

Steps vertical reverse {steps}

Adding Icons

Enhance your steps by adding icons!

let steps = [
    { text: "step one", icon: IconMoney },
    { text: "step two", icon: IconPaperClip },
    { text: "the last step", icon: IconPerson }
];

Customizing Appearance

With the Steps component, you can manipulate various styles:

Square Steps:

Steps {steps} borderRadius=0

Customize Color:

Steps {steps} primary="#ff0000" secondary="#ffaaaa"

Change Size:

Steps {steps} size="2rem" line="2px"

No Text Option:

let steps = [
        { icon: IconMoney },
        { icon: IconPaperClip },
        { icon: IconPerson }
    ];

Using Alert and Custom Icons:

import Escalation from './YourEscalation.svelte';
    let steps = [
        { text: "step one", alert: true },
        { text: "step two" },
        { text: "the last step" }
    ];
    Steps {steps} alertColor="#ff00ff" alertIcon={Escalation} checkIcon={null}

Events

To handle click events within the Steps component, use this:

Steps {steps}
    current
    on:click={(e) => {
        last = e.detail.last;
        current = e.detail.current;
    }};

Integrate with Bootstrap

The component integrates seamlessly with Bootstrap. Just make sure to include Bootstrap’s CSS in your app’s HTML header:

<head>
    <link href="https://cdn.jsdelivr.net/npm/bootstrap@5.0.2/dist/css/bootstrap.min.css" rel="stylesheet" integrity="sha384-EVSTQN3azprG1Anm3QDgpJLIm9Nao0Yz1ztcQTwFspd3yD65VohhpuuCOmLASjC" crossorigin="anonymous">
</head>

Props Overview

Here’s a breakdown of the properties you can use for the Steps component:

steps: Array of step objects (Required).
current: Current step index (Default: 0).
size: Size of step buttons (Default: 3rem).
line: Thickness of connecting lines (Default: 0.3rem).
primary: Color for current and passed steps (Default: Bootstrap primary).
secondary: Color for future steps (Default: Bootstrap secondary).
borderRadius: Shape of step buttons (Default: 50%).
clickable: Controls click behavior (Default: true).

Troubleshooting

If you encounter any issues while implementing the Svelte steps component, consider these troubleshooting steps:

Ensure you’re using Svelte version 3.46.3 or newer if you’re trying to implement vertical steps.
Double-check your props to make sure they are correctly defined and not empty.
Make sure Bootstrap CSS is properly linked; otherwise, the styles won’t apply as intended.
If components aren’t rendering correctly, restart your development server.
If issues persist, consider checking the official documentation for further insights.

For more insights, updates, or to collaborate on AI development projects, stay connected with fxis.ai.

Conclusion

Now you have the knowledge to create a customizable step component in your Svelte application! Use it to enhance your user experience with visual guidance throughout different processes. At fxis.ai, we believe that such advancements are crucial for the future of AI, as they enable more comprehensive and effective solutions. Our team is continually exploring new methodologies to push the envelope in artificial intelligence, ensuring that our clients benefit from the latest technological innovations.
