Are you looking to add a dynamic and visually appealing feature to your Android application? The Expanding Collection is a fantastic material design card peek/pop controller that enhances user experience with its unique collapsing and expanding card views. Let’s dive into how you can implement this library in your Android application.

Requirements

• Android 4.0 Ice Cream Sandwich (API level 14) or greater
• Your favorite IDE (e.g., Android Studio)

Installation

To get started, add the Expanding Collection library to your project. Here’s how you can do it using different build systems:

• Gradle: Add the following line to your build.gradle file:

implementation 'com.ramotion.expandingcollection:expanding-collection:0.9.2'

• SBT: Include in your SBT build file:

libraryDependencies += "com.ramotion.expandingcollection" % "expanding-collection" % "0.9.2"

• Maven: Add the following in your pom.xml:

<dependency>
    <groupId>com.ramotion.expandingcollection</groupId>
    <artifactId>expanding-collection</artifactId>
    <version>0.9.2</version>
</dependency>

Basic Usage

Let’s break down the implementation process into simple steps:

Step 1: Add Layout Elements

Add two essential elements to your layout: the ECBackgroundSwitcherView for dynamic backgrounds, and the ECPagerView for the expanding cards:

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <com.ramotion.expandingcollection.ECBackgroundSwitcherView
        android:id="@+id/ec_bg_switcher_element"
        android:layout_width="match_parent"
        android:layout_height="match_parent"/>

    <com.ramotion.expandingcollection.ECPagerView
        android:id="@+id/ec_pager_element"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_centerInParent="true"/>

</RelativeLayout>

Step 2: Configure the `ECPagerView`

Set up the size of the card in its collapsed state and the height of the header when expanded:

<com.ramotion.expandingcollection.ECPagerView
    xmlns:ec="http://schemas.android.com/apk/res-auto"
    android:id="@+id/ec_pager_element"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_centerInParent="true"
    ec:cardHeaderHeightExpanded="150dp"
    ec:cardHeight="200dp"
    ec:cardWidth="250dp"/>

Step 3: Create a Custom List Adapter

Next, implement a custom list adapter for list items. This is where we define how our data should be displayed:

public class CardListItemAdapter extends ECCardContentListItemAdapter<String> {
    public CardListItemAdapter(@NonNull Context context, @NonNull List<String> objects) {
        super(context, R.layout.list_item, objects);
    }

    @NonNull
    @Override
    public View getView(int position, @Nullable View convertView, @NonNull ViewGroup parent) {
        ViewHolder viewHolder;
        View rowView = convertView;

        if (rowView == null) {
            LayoutInflater inflater = LayoutInflater.from(getContext());
            rowView = inflater.inflate(R.layout.list_item, null);
            viewHolder = new ViewHolder();
            viewHolder.itemText = (TextView) rowView.findViewById(R.id.list_item_text);
            rowView.setTag(viewHolder);
        } else {
            viewHolder = (ViewHolder) rowView.getTag();
        }

        String item = getItem(position);
        if (item != null) {
            viewHolder.itemText.setText(item);
        }

        return rowView;
    }

    static class ViewHolder {
        TextView itemText;
    }
}

Step 4: Implement the `ECPagerViewAdapter`

Finally, provide your dataset to a pager element through a pager adapter. Here’s an example:

public class MainActivity extends Activity {
    private ECPagerView ecPagerView;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        ecPagerView = (ECPagerView) findViewById(R.id.ec_pager_element);
        List<ECCardData> dataset = CardDataImpl.generateExampleData();

        ecPagerView.setPagerViewAdapter(new ECPagerViewAdapter(getApplicationContext(), dataset) {
            @Override
            public void instantiateCard(LayoutInflater inflaterService, ViewGroup head, ListView list, ECCardData data) {
                CardDataImpl cardData = (CardDataImpl) data;
                list.setAdapter(new CardListItemAdapter(getApplicationContext(), cardData.getListItems()));
                // Set head view components here.
            }
        });

        // Add background switcher to pager
        ecPagerView.setBackgroundSwitcherView((ECBackgroundSwitcherView) findViewById(R.id.ec_bg_switcher_element));
    }
}

Troubleshooting Common Issues

If you encounter any issues while implementing the Expanding Collection, here are some troubleshooting tips:

• Ensure Correct Library Version: Double-check that you’ve included the correct version of the library in your project dependencies.
• Check for Layout Issues: Ensure that your XML layouts are correctly set up and that all IDs match what you reference in your code.
• Debugging the Card Load: If cards are not loading as expected, look for any potential null pointers or issues in data initialization.
