If you’re looking to dive into the world of high-fidelity Neural Radiance Fields for human motion, HumanRF is your gateway. This detailed guide will walk you through the installation and usage of HumanRF and ActorsHQ step-by-step, ensuring you can set things up smoothly. Let’s get started!

Installation Steps

To successfully install HumanRF and its dependencies, follow these steps:

bash
# Clone the repository
git clone --depth=1 --recursive https://github.com/synthesiaresearch/humanrf

# Install GLM
sudo apt-get install libglm-dev

# Install required packages and Tiny CUDA NN
pip install -r requirements.txt
pip install git+https://github.com/NVlabs/tiny-cuda-nn#subdirectory=bindings/torch

# Install ActorsHQ package (dataset and data loader)
cd actorshq
pip3 install .

# Install HumanRF package (method)
cd ..
cd humanrf
pip3 install .

# Add the installation folder to the PYTHONPATH
export PYTHONPATH=$PYTHONPATH:/pathtorepo

Understanding the Installation Process

Think of installing HumanRF like building a house. First, you lay the foundation (cloning the repository) and then you install the essential frameworks (GLM and packages) as the building blocks. Next, you set up rooms (ActorsHQ package) and finalize with decor (HumanRF package). The PYTHONPATH is like ensuring your address is clear so all visitors know where to go!

Getting Started with Usage

Once you have everything set up, downloading a part of ActorsHQ and running HumanRF is straightforward:

bash
# Download dataset
python actorshq/dataset/download_manager.py actorshq_access_4x.yaml tmpactorshq --actor Actor01 --sequence Sequence1 --scale 4 --frame_start 15 --frame_stop 65

# Run HumanRF
python humanrf/run.py --config example_humanrf --workspace tmp/example_workspace --dataset.path tmpactorshq

Data Overview

The downloaded data will be structured similarly to this:

• Actor01
  • Sequence1
    • calibration.csv – Camera calibration data
    • light_annotations.csv – 2D annotations for light sources
    • masks – Per-frame mask for each camera
    • rgbs – Per-frame RGB images with background removed
    • aabbs.csv – Per-frame axis-aligned bounding boxes of the meshes
    • occupancy_grids – Per-frame occupancy grids
    • meshes.abc – Per-frame meshes in Alembic format
    • scene.blend – Blender scene file visualizing meshes, cameras, and RGB images
    • scene.json – Scene description file storing the number of frames

Calibration and Visualization

Calibration data is provided in a calibration.csv file, detailing various camera parameters. To visualize the cameras in 3D, you can run a snippet provided in the documentation.

Troubleshooting

If you encounter issues during installation or usage, here are some common troubleshooting steps:

• Ensure that all dependencies are installed, especially GLM and Tiny CUDA NN.
• Verify that PYTHONPATH is set correctly.
• Check the YAML file permissions for reading the dataset.
