EfficientNet-B3 is a powerful image classification model trained on the ImageNet-1k dataset using the TIMM library. In this guide, we’ll walk you through the steps necessary to implement this model, extract features, and obtain image embeddings. We’ll also address common troubleshooting scenarios. Let’s dive in!

What Is EfficientNet-B3?

EfficientNet-B3 is a neural network model optimized for performance while maintaining low computational complexity. Think of it like a high-performance car designed for both speed and fuel efficiency. Instead of trading performance for efficiency, EfficientNet scales both aspects harmoniously, offering excellent results in image classification tasks.

Getting Started: Prerequisites

• Ensure you have Python installed on your machine.
• Install the necessary libraries, including PIL and timm.
• Make sure you have access to the internet to load images from URLs.

How to Classify an Image

Here’s a step-by-step code snippet to classify an image using EfficientNet-B3.

python
from urllib.request import urlopen
from PIL import Image
import timm

# Load the image
img = Image.open(urlopen('https://huggingface.co/datasets/huggingface/documentation-images/resolve/main/beignets-task-guide.png'))

# Create the model
model = timm.create_model('efficientnet_b3.ra2_in1k', pretrained=True)
model = model.eval()

# Get model specific transforms (normalization, resize)
data_config = timm.data.resolve_model_data_config(model)
transforms = timm.data.create_transform(**data_config, is_training=False)

# Classify the image
output = model(transforms(img).unsqueeze(0))  # Unsqueeze single image into batch of 1
top5_probabilities, top5_class_indices = torch.topk(output.softmax(dim=1) * 100, k=5)

This code snippet loads an image from the web, creates an EfficientNet-B3 model, and passes the image through the model to classify it. The top five probabilities and corresponding class indices are stored in variables for further processing.

Extracting Feature Maps

Want to get a peek into the inner workings of EfficientNet? Use feature maps to visualize the transformations happening at each layer. Here’s how:

python
# Load the image again
img = Image.open(urlopen('https://huggingface.co/datasets/huggingface/documentation-images/resolve/main/beignets-task-guide.png'))

# Create the model with features_only=True
model = timm.create_model('efficientnet_b3.ra2_in1k', pretrained=True, features_only=True)
model = model.eval()

# Extract feature maps
output = model(transforms(img).unsqueeze(0))  # Unsqueeze single image into batch of 1
for o in output:
    print(o.shape)  # Print shape of each feature map in output

This will give you the shapes of the feature maps, allowing you to understand how information is transformed at different layers of the EfficientNet architecture.

How to Obtain Image Embeddings

If you’re interested in obtaining embeddings instead of classifications, you can do this as follows:

python
# Load the image
img = Image.open(urlopen('https://huggingface.co/datasets/huggingface/documentation-images/resolve/main/beignets-task-guide.png'))

# Create the model to extract features
model = timm.create_model('efficientnet_b3.ra2_in1k', pretrained=True, num_classes=0)
model = model.eval()

# Obtain embeddings
output = model(transforms(img).unsqueeze(0))  # Output is (batch_size, num_features) shaped tensor

Here, the model outputs a tensor representing the embeddings of the image, which are useful for various downstream tasks, such as clustering and similarity searches.

Troubleshooting Tips

If you encounter issues while following this guide, consider the following troubleshooting options:

• Ensure the input image URL is valid and accessible.
• Check that all necessary libraries are installed and up-to-date.
• Inspect the shape of the input tensor; it should match the expected format for your model.
• If you receive model errors or warnings, ensure that your Python environment is properly set up.

For more insights, updates, or to collaborate on AI development projects, stay connected with fxis.ai.

Conclusion

EfficientNet-B3 is a remarkable tool in the field of image classification, offering powerful features that cater to various AI applications. Whether you’re interested in classification, feature extraction, or obtaining embeddings, this guide provides you with the foundational steps needed to get started.
