Inkdrop is a CLI tool that creates interactive diagrams to visualize your Terraform. It helps you onboard engineers, generate documentation, and understand dependencies faster.

Overview

Inkdrop generates a visual, interactive map of your resources, helping you understand relationships and dependencies. Allowing you to quickly review infrastructure and onboard new engineers with ease.

Installation

To start using Inkdrop, you can install it using one of the following methods:

• With Brew:

  brew tap inkdrop-org/inkdrop-visualizer
  brew install inkdrop-visualizer

• With Linux:

  wget https://github.com/inkdrop-org/inkdrop-visualizer/releases/latest/download/inkdrop-linux-x64.tar.gz
  tar -xzf inkdrop-linux-x64.tar.gz
  chmod +x inkdrop
  mv inkdrop /usr/local/bin

• With NPM:

  npm install -g inkdrop-visualizer

• With Docker:

Usage

To use Inkdrop, run it where you would normally execute Terraform commands:

inkdrop
terraform init
terraform plan -out plan.out
inkdrop plan.out

This will launch an interactive WebUI, showing you which resources will change based on your tf.plan. By clicking on a resource, you can view additional details, including variables and outputs used, while also filtering by resource type and tags.

Command Line Arguments

Here are some command line arguments you can use with Inkdrop:

Argument	Description	Example Usage
(no argument)	Automatically launches a browser tab to display the diagram interactively.	inkdrop
plan-filename	Visualizes changes from a specified terraform plan file.	inkdrop plan.out
–state-dirs	List of directories with Terraform configuration files to visualize multiple states.	inkdrop plan.out –state-dirs . /pathtotfdir1 /pathtotfdir2
–help, -h	Displays help information about the CLI tool.	inkdrop –help
–version, -v	Shows the current version number.	inkdrop –version
–debug	Shows logs for diagram generation.	inkdrop –debug
–path	Sets the working directory for a specified Terraform project path.	inkdrop –path .repos/my-tf-project
–renderer-port	Defines the port for the local diagram rendering service (default: 3000).	inkdrop –renderer-port 8080

CI Usage

To use Inkdrop in your CI process, check out these integrations:

• GitHub example
• Atlantis example
• GitLab example (coming soon)

The runner will comment an SVG Image in the PR. Using the Inkdrop extension, this image becomes interactive and behaves like the CLI version when clicked.

Docker Usage

To run Inkdrop using Docker, use the following command:

docker run -v pathtoyourterraformroot:tfroot \
--env TF_VERSION=1.5.7 \
-p 3000:3000 \
-it inkdroporg/inkdrop:latest plan.out [additional arguments]

Replace pathtoyourterraformroot with your local Terraform root directory. Ensure that the TF_VERSION matches your local Terraform version.

Troubleshooting

If you encounter any issues during your experience with Inkdrop, a good starting point is to use the --debug flag and report any issues you find. Together we can resolve any concerns!
