If you’re looking to create beautiful floating overlays—like tooltips, menus, and dialogs—in your Flutter applications, the flutter_portal library is your go-to solution. This library provides an enhanced way to manage overlays compared to Flutter’s built-in options. Let’s dive into how you can implement it effectively!

Why Choose flutter_portal?

• Declarative Approach: Unlike Flutter’s built-in Overlay, which relies on imperatives, flutter_portal allows you to declare your UI in a more intuitive way.
• Easy Alignment: Position overlays relative to UI components effortlessly, eliminating the complexity of manual positioning.
• Customizable Alignment Logic: Ensure your overlays never go off-screen and even extend the default alignment methods to fit your needs.
• Intuitive Contextual Awareness: Overlays use their parent’s context, which provides access to themes and other providers seamlessly.

Setting Up flutter_portal

To get started with flutter_portal, follow these steps:

1. Install the Library: Use the command:

   flutter pub add flutter_portal

2. Add the Portal Widget: Insert the Portal widget at the root of your widget tree or just above the MaterialApp.
3. Creating Portal Targets: Use PortalTarget when you want to display overlays connected with corresponding interface elements.

Creating a Contextual Menu Example

Let’s take a look at a practical example of how to create a contextual menu that appears when a button is pressed. Consider the flutter portal’s components in the same way that you might use a stage in a theater: you have your main act (the button) and you can bring in various props (the overlay menu) as needed.

Portal(
  child: MaterialApp(
    home: MenuExample()
  )
)

class MenuExample extends StatefulWidget {
  @override
  _MenuExampleState createState() => _MenuExampleState();
}

class _MenuExampleState extends State {
  bool isMenuOpen = false;

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Center(
        child: RaisedButton(
          onPressed: () {
            setState(() {
              isMenuOpen = true; // Triggers the menu to show
            });
          },
          child: Text('Show Menu'),
        ),
      ),
    );
  }
}

Adjusting the Menu’s Position

To align the menu next to your button, you adjust its parameters in the PortalTarget:

PortalTarget(
  visible: isMenuOpen,
  anchor: const Aligned(
    follower: Alignment.topLeft,
    target: Alignment.topRight,
  ),
  portalFollower: Material(
    elevation: 8,
    child: Column(
      mainAxisSize: MainAxisSize.min,
      children: [
          ListTile(title: Text('Option 1')),
          ListTile(title: Text('Option 2')),
      ],
    ),
  ),
  child: RaisedButton(
    onPressed: () {
      setState(() {
        isMenuOpen = false; // Close the menu
      });
    },
    child: Text('Show Menu'),
  ),
)

Troubleshooting Common Issues

While using flutter_portal, you might encounter some common issues. Here are some troubleshooting tips:

• Menu Not Displaying: Make sure that your PortalTarget is properly aligned and visible is set to true.
• Incorrect Theming: Check if your overlay components are inheriting the right Theme context from their parent widgets.
• Overlays Going Off-Screen: Utilize the customizable alignment logic to ensure your overlays are within screen bounds.
