Multi-object Reasoning for 6D Pose Estimation from Volumetric Fusion

MoreFusion is an object-level reconstruction system that builds a map with known-shaped objects, exploiting volumetric reconstruction of detected objects in a real-time, incremental scene reconstruction scenario. The key components are:

• Occupancy-based volumetric reconstruction of detected objects for model alignment in a later stage;
• Volumetric pose prediction that exploits volumetric reconstruction and CNN feature extraction from the image observation;
• Joint pose refinement of objects based on geometric consistency among objects and impenetrable space.

Installation

There are several options for installation:

• Python project only: Python framework for pose estimation (e.g., training, inference, refinement).
• ROS project for camera demonstration: ROS framework for object-level mapping with live cameras.
• ROS project for robotic demonstration: ROS framework for robotic demonstration with object-level mapping.

NOTE: We developed this project on Ubuntu 16.04 (and ROS Kinetic, CUDA 10.1), so several code changes may be needed to adapt to other OS (and ROS, CUDA versions).

Python project only

bash
make install
source .anaconda3binactivate

ROS project for camera demonstration

bash
cd ros
make install
source ...anaconda3binactivate
source devel/setup.sh

ROS project for robotic demonstration

– robot-agent: A computer with CUDA and a GPU for visual processing.

– robot-node: A computer with a real-time OS for a Panda robot.

@robot-agent

Same as above instruction:ROS project for camera demonstration.

@robot-node

bash
cd ros
catkin build morefusion_ros_panda
source devel/setup.sh
rosrun morefusion_ros_panda create_udev_rules.sh

Usage

Training and Inference

Pre-trained models are provided in the demos as follows, so this process is optional to run the demos.

• Pre-trained instance segmentation model
• Pre-trained 6D pose prediction model

Instance Segmentation

bash
cd examples/ycb_video
instance_segm.download_dataset.py
mpirun -n 4 python train_multi.py  # 4-gpu training.
image_demo.py --model logsXXXXXX.npz

6D Pose Prediction

# baseline model (point-cloud-based)
cd examples/ycb_video
singleview_pcd.download_dataset.py
train.py --gpu 0 --centerize-pcd --pretrained-resnet18  # 1-gpu
mpirun -n 4 .train.py --multi-node --centerize-pcd --pretrained-resnet18  # 4-gpu
# volumetric prediction model (3D-CNN-based)
cd examples/ycb_video
singleview_3d.download_dataset.py
train.py --gpu 0 --pretrained-resnet18 --with-occupancy  # 1-gpu
mpirun -n 4 .train.py --multi-node --pretrained-resnet18 --with-occupancy  # 4-gpu
mpirun -n 4 .train.py --multi-node --pretrained-resnet18  # wo occupancy
# inference
download_pretrained_model.py  # for downloading pretrained model.
demo.py logsXXXXXX.npz
evaluate.py logsXXX

Joint Pose Refinement

bash
cd examples/ycb_video
pose_refinement.check_icp_vs_icc.py  # press [s] to start

Camera Demonstration

Static Scene

# using orb-slam2 for camera tracking
roslaunch morefusion_ros rs_rgbd.launch
roslaunch morefusion_ros rviz_static.desk.launch
roslaunch morefusion_ros setup_static.desk.launch

# using robotic kinematics for camera tracking
roslaunch morefusion_ros rs_rgbd.robot.launch
roslaunch morefusion_ros rviz_static.robot.launch
roslaunch morefusion_ros setup_static.robot.launch

Dynamic Scene

bash
roslaunch morefusion_ros rs_rgbd.launch
roslaunch morefusion_ros rviz_dynamic.desk.launch
roslaunch morefusion_ros setup_dynamic.desk.launch
roslaunch morefusion_ros rs_rgbd.robot.launch
roslaunch morefusion_ros rviz_dynamic.robot.launch
roslaunch morefusion_ros setup_dynamic.robot.launch

Robotic Demonstration

Robotic Pick-and-Place

bash
robot-agent $ sudo ntpdate 0.uk.pool.ntp.org  # for time synchronization
robot-node  $ sudo ntpdate 0.uk.pool.ntp.org  # for time synchronization
robot-node  $ roscore
robot-agent $ roslaunch morefusion_ros_panda panda.launch
robot-node  $ roslaunch morefusion_ros rs_rgbd.robot.launch
robot-node  $ roslaunch morefusion_ros rviz_static.launch
robot-node  $ roslaunch morefusion_ros setup_static.robot launch TARGET:=2
robot-node  $ rosrun morefusion_ros robot_demo_node.py ri.run()

Figure 4: Targetted Object Pick-and-Place. (a) Scanning the Scene; (b) Removing Distractor Objects; (c) Picking Target Object.

Troubleshooting

If you run into issues during installation or execution, consider the following tips:

• Ensure all dependencies specified in the documentation are installed on your system.
• Check if you’re using compatible versions of Ubuntu, ROS, and CUDA.
• Refer to the errors in the console during runtime for specific guidance on what might be going wrong.
• Visit the official webpage for additional resources or contact support.
