Ethereum’s Modified Merkle Patricia Trie (MPT) is an essential component of its blockchain architecture, offering a way to efficiently store key-value pairs while ensuring data integrity. This blog post aims to guide you through a simplified implementation of MPT in Golang, focusing on its features and structure, as well as providing troubleshooting insights.

Introduction to the Modified Merkle Patricia Trie

This implementation is a streamlined version of Ethereum’s MPT, as specified in the Ethereum Yellow Paper. The main focus of this implementation is to help learners grasp the underlying algorithm and data structure, without delving into complexities like tree encoding, decoding, or data persistence.

Implementing Key-Value Mapping

The MPT acts as a key-value mapping system with the following basic methods:

• Get(key []byte) ([]byte, bool) – Retrieves a value based on the provided key.
• Put(key []byte, value []byte) – Inserts or updates a key-value pair.
• Del(key []byte) bool – Deletes the specified key-value pair.

Example Tests

To ensure that our Trie implementation adheres to these methods, we can run a series of tests:

func TestGetPut(t *testing.T) {
    t.Run("should get nothing if key does not exist", func(t *testing.T) {
        trie := NewTrie()
        _, found := trie.Get([]byte("notexist"))
        require.Equal(t, false, found)
    })

    t.Run("should get value if key exists", func(t *testing.T) {
        trie := NewTrie()
        trie.Put([]byte{1, 2, 3, 4}, []byte("hello"))
        val, found := trie.Get([]byte{1, 2, 3, 4})
        require.Equal(t, true, found)
        require.Equal(t, val, []byte("hello"))
    })

    t.Run("should get updated value", func(t *testing.T) {
        trie := NewTrie()
        trie.Put([]byte{1, 2, 3, 4}, []byte("hello"))
        trie.Put([]byte{1, 2, 3, 4}, []byte("world"))
        val, found := trie.Get([]byte{1, 2, 3, 4})
        require.Equal(t, true, found)
        require.Equal(t, val, []byte("world"))
    })
}

Verifying Data Integrity

What sets the Merkle Patricia Trie apart from typical mappings is its capability to verify data integrity through the computation of a Merkle Root Hash. If any key-value pair changes, the root hash reflects this modification. This consistency means that if two tries have identical key-value pairs, they will share the same Merkle Root Hash.

Understanding with Test Cases

We can further exemplify this behavior with specific tests:

func TestDataIntegrity(t *testing.T) {
    t.Run("should get a different hash if a new key-value pair is added or updated", func(t *testing.T) {
        trie := NewTrie()
        hash0 := trie.Hash()
        trie.Put([]byte{1, 2, 3, 4}, []byte("hello"))
        hash1 := trie.Hash()
        trie.Put([]byte{1, 2}, []byte("world"))
        hash2 := trie.Hash()
        require.NotEqual(t, hash0, hash1)
        require.NotEqual(t, hash1, hash2)
    })

    t.Run("should get the same hash if two tries have identical key-value pairs", func(t *testing.T) {
        trie1 := NewTrie()
        trie1.Put([]byte{1, 2, 3, 4}, []byte("hello"))
        trie1.Put([]byte{1, 2}, []byte("world"))

        trie2 := NewTrie()
        trie2.Put([]byte{1, 2, 3, 4}, []byte("hello"))
        trie2.Put([]byte{1, 2}, []byte("world"))

        require.Equal(t, trie1.Hash(), trie2.Hash())
    })
}

Proof and Verification

An exciting feature of the Trie is its capability to prove the inclusion of a key-value pair without needing access to the full set of entries. This feature is vital for Ethereum light clients, which can verify their account balances without downloading the entire blockchain.

Example Tests for Proof

Here’s how we can test the proof-generating functionality:

func TestProveAndVerifyProof(t *testing.T) {
    t.Run("should not generate proof for non-existent key", func(t *testing.T) {
        tr := NewTrie()
        tr.Put([]byte{1, 2, 3}, []byte("hello"))
        notExistKey := []byte{1, 2, 3, 4}
        _, ok := tr.Prove(notExistKey)
        require.False(t, ok)
    })

    t.Run("should generate proof for existing key", func(t *testing.T) {
        tr := NewTrie()
        tr.Put([]byte{1, 2, 3}, []byte("hello"))
        key := []byte{1, 2, 3}
        proof, ok := tr.Prove(key)
        require.True(t, ok)

        rootHash := tr.Hash()
        val, err := VerifyProof(rootHash, key, proof)
        require.NoError(t, err)
        require.Equal(t, []byte("hello"), val)
    })
}

Implementing the Trie with Ethereum Data Verification

To validate your implementation, you can cross-reference it with Ethereum’s mainnet data. For instance, Ethereum utilizes three distinct tries—Transaction Trie, Receipt Trie, and State Trie. You could compare the root hashes obtained from your implementation with those on the mainnet to ensure accuracy.

Capture Test Cases for Transactions

In order to check these transactions, create a scenario where you add transactions from a certain block and confirm the Merkle root hash matches the Ethereum transaction root:

func TestTransactionRootAndProof(t *testing.T) {
    trie := NewTrie()
    // Assume txs are loaded from a JSON file
    for i, tx := range txs {
        key, err := rlp.EncodeToBytes(uint(i))
        require.NoError(t, err)
        // Example of putting transaction into the trie
        // ...
    }
    // Verify that the computed root hash matches the expected hash
}

Understanding the Trie Structure Internally

The internal structure of the Merkle Patricia Trie utilizes four node types: EmptyNode, LeafNode, BranchNode, and ExtensionNode. Each serves a unique role in managing and storing data efficiently. As transactions are added, nodes change in type according to rules, which is essential for maintaining integrity and accessibility.

Visualizing Node Changes

You can inspect the changes in the trie by visualizing how nodes interact when transactions are added:

• Initially, it starts with an EmptyNode.
• As new transactions are added, LeafNodes are created and updated as needed.
• BranchNodes can be established for multiple paths, allowing for efficient querying of keys.

Troubleshooting Common Issues

If you encounter issues with your implementation, consider the following troubleshooting steps:

• Ensure all input keys and values are correctly formatted.
• Double-check the handling of node types—particularly with Branch or Empty nodes.
• Run the provided test cases to verify that all methods are functioning properly.

For more insights, updates, or to collaborate on AI development projects, stay connected with fxis.ai.

Conclusion

In summary, the Modified Merkle Patricia Trie serves as an efficient structure for key-value storage that also enforces data integrity. By following the guidelines in this blog post, you can implement and understand this powerful data structure in Golang.
