GSTools is a powerful library designed for geostatistical modelling, providing an array of features for tasks such as random field generation, kriging, variogram estimation, and much more. From generating fields to plotting and exporting data, GSTools simplifies complex geostatistical processes. This blog will guide you through the installation process and showcase some key functionalities of GSTools.

Installation of GSTools

You can elevate your Python environment with GSTools by installing it via either conda or pip. Here’s how:

Installing GSTools with Conda

For users on Linux, Mac, and Windows, type the following command in your terminal:

conda install gstools

If Conda Forge isn’t set up for your system just yet, you can follow easy-to-follow instructions here.

Installing GSTools with Pip

If you prefer using pip, you can follow these steps. On Windows, install WinPython first to ensure Python and pip are running.

Then, use this command to install:

pip install gstools

For the latest development version, follow the directions provided in the documentation.

Generating Spatial Random Fields

The heart of GSTools is its ability to generate spatial random fields. Imagine you are an artist creating a beautiful landscape; each brushstroke varies based on certain rules, resulting in a mesmerizing picture. Similarly, GSTools generates random fields based on mathematical models. Let’s look at how the Gaussian covariance model works:

In our analogy, the Gaussian model acts like the artist’s brush that creates patterns within the canvas. Here’s how to generate a 2D spatial random field:

import gstools as gs
x = y = range(100)  # The canvas's domain
model = gs.Gaussian(dim=2, var=1, len_scale=10)  # Artist's brush
srf = gs.SRF(model)  # Create the random field
srf((x, y), mesh_type='structured')  # Fill in the masterpiece
srf.plot()  # Show the artwork

Visualizing with Geographic Coordinates

GSTools even supports geographic coordinates, allowing you to paint landscapes based on real-world data. Here’s a setup to visualize your random field using Cartopy:

import matplotlib.pyplot as plt
import cartopy.crs as ccrs
import gstools as gs

lat = lon = range(-80, 81)  # Latitude and longitude ranges
model = gs.Gaussian(latlon=True, len_scale=777, geo_scale=gs.KM_SCALE)  # Model setup
srf = gs.SRF(model, seed=12345)  # Create random field with a seed
field = srf.structured((lat, lon))

ax = plt.subplot(projection=ccrs.Orthographic(-45, 45))  # Setting up the plot projection
cont = ax.contourf(lon, lat, field, transform=ccrs.PlateCarree())
ax.coastlines()  # Add coastlines for context
ax.set_global()  # Global extent
plt.colorbar(cont)  # Colorbar indicates field values

Estimating Variograms

To analyze a field’s spatial structure, variograms depict how data varies across space. Like examining the brush strokes up close to catch finer details, GSTools provides tools for estimating and fitting variograms:

import numpy as np
import gstools as gs

x = np.random.RandomState(19970221).rand(1000) * 100
y = np.random.RandomState(20011012).rand(1000) * 100
model = gs.Exponential(dim=2, var=2, len_scale=8)  # Model for variogram
srf = gs.SRF(model, mean=0, seed=19970221)
field = srf((x, y))  # Generate field

bin_center, gamma = gs.vario_estimate((x, y), field)  # Estimating variogram
fit_model = gs.Stable(dim=2)
fit_model.fit_variogram(bin_center, gamma, nugget=False)  # Fitting model

Troubleshooting Common Issues

While navigating through GSTools, you may face a few hiccups. Here are some common issues and how to resolve them:

• Module Not Found: Ensure you have installed GSTools correctly with either conda or pip.
• Visualization Errors: If your plots are not displaying, check if you have the necessary plotting libraries installed, such as Matplotlib or Cartopy.
• Function Compatibility: Review the GSTools documentation to ensure function usage matches your intended application. Each version might include updates or changes.
